Forma LC - Ethanol burner insert
Prices incl. VAT.
All prices include VAT plus shipping costs. Free shipping for orders over €500 (DE, excluding islands). All dimensions are approximate. Subject to changes and errors. Illustrations may contain special equipment, decorations and optional accessories. Ethanol fireplaces do not replace heating. Due to the current situation, some items are not in stock or are only available in limited quantities from us or the manufacturer, or have a longer delivery time, so unfortunately this cannot be stated on a daily basis. Please feel free to contact us by phone or email.
delivery time
Delivery time on request.
We would be happy to advise you by phone: +49(0)5481 93 67-50
Forma - Burning insert
Metal insert - opened on the left side (left corner)
Bio-ethanol automatic burner (FLA3/FLA3+) with BEV technology®
Remote control, app control*, 6-stage flame regulation*, smart home (optional)*
• 6 different widths (approx. 100-270 cm)
• 7 different opening options
• optionally available with larger tank (FLA3+)
General data for all versions / details see below:
Width/Length: 102/122/153/183/234/270 cm
Height: 50.8 cm
Depth: 40.6 cm
• Remote control
• WiFi*
• App control*
• 6-stage flame regulation*
• automatic filling system (pump system)
• SHS control (smart home) optionally available (cannot be retrofitted)*
• Large filling capacity optionally available (FLA3+)
Surface: black, powder-coated
Material: steel, galvanized steel, safety glass
Power supply: 230 V
• for indoor use only
Hints:
• All necessary glass panes are included in the delivery. (2 larger panes each for the tunnel, island and three-sided versions)
• Also available in a larger capacity version (FLA3+).
• An optional shelf for stones or decorative wood is available, which can be placed behind the flame.
• An individual surface (stainless steel/color) has a delivery time of approx. 5 weeks.
• Individual housing/burner lengths (custom-made) on request. Delivery time approx. 6 weeks.
* For the "Forma 1200" model, in addition to the automatic burners FLA3 and FLA3+, the simpler bio-ethanol burner "Prime Fire 990+" is also available. This has a remote control and 2-stage flame regulation. App control (WiFi) and SHS control are not possible with this model. For further details on the burner, see below.
Viewing opening in cm | Width |
Height |
depth |
Forma 1000 incl. FLA3(+) 790 | 101.6 |
50.8 | 40.6 |
Forma 1200 incl. FLA3(+) 990 alternatively with Prime Fire 990+ |
121.9 | 50.8 | 40.6 |
Forma 1500 incl. FLA3(+) 1190 | 152.4 | 50.8 | 40.6 |
Forma 1800 incl. FLA3(+) 1490 | 182.9 | 50.8 | 40.6 |
Forma 2300 incl. FLA3(+) 1990 | 233.7 | 50.8 | 40.6 |
Forma 2700 incl. FLA3(+) 2490 | 269.3 | 50.8 | 40.6 |
The installation dimensions are correspondingly larger. |
Built-in burner | Wide length | Height | depth | Contents | Burning time | Heat emission | Weight | Minimum room size |
FLA3 790 FLA3+ 790 |
79cm Fire: 60 cm Glass: 71 cm |
22 cm (including glass: 27.4 cm) 30.5 cm (including glass: 35.9 cm) |
28cm |
4.3L 13.4L |
max. 9 hours max. 29 hours |
4.4kW/h |
24.1kg 32kg |
44 m³ |
FLA3 990 FLA3+ 990 |
99cm Fire: 80 cm Glass: 93 cm |
22 cm (including glass: 27.4 cm) 30.5 cm (including glass: 35.9 cm) |
28cm |
5.3L 17.2L |
max. 10 hours max. 31 hours |
7kW/h |
27.5kg 38.5kg |
70 m³ |
FLA3 1190 FLA3+ 1190 |
119cm Fire: 100 cm Glass: 111 cm |
22 cm (including glass: 27.4 cm) 30.5 cm (including glass: 35.9 cm) |
28cm |
6.8L 21L |
max. 11 hours max. 35 hours |
9.4kW/h |
33kg 44kg |
94 m³ |
FLA3 1490 FLA3+ 1490 |
149cm Fire: 130 cm Glass: 142 cm |
22 cm (including glass: 27.4 cm) 30.5 cm (including glass: 35.9 cm) |
28cm |
8.6L 26.8L |
max. 11 hours max. 35 hours |
13 kW/h |
39.5kg 52.5kg |
130 m³ |
FLA3 1990 FLA3+ 1990 |
199cm Fire: 180 cm Glass: 186 cm |
22 cm (including glass: 27.4 cm) 30.5 cm (including glass: 35.9 cm) |
28cm |
11.7L 36.3L |
max. 12 hours max. 36 hours |
18 kW/h |
49.5kg 67.5kg |
180 m³ |
FLA3 2490 FLA3+ 2490 |
249cm Fire: 230 cm Glass: 241 cm |
22 cm (including glass: 27.4 cm) 30.5 cm (including glass: 35.9 cm) |
28cm |
14.8L 45.9L |
max. 12 hours max. 36 hours |
22.5kW/h |
58.5kg 81.5kg |
225 m³ |
PrimeFire 990+ | 99cm Fire: 80 cm Glass: 93 cm |
22 cm (including glass: 27.4 cm) |
28cm |
5.5L |
max. 10 hours | 7kW/h |
27.5kg |
70 m³ |
Burning time at the lowest flame setting. Heat output at the highest flame setting. Air exchange rate 1/hour. Power connection 230 V. The Prime Fire 990+ model has a 2-stage flame regulation (standard/eco) with a remote control (NO WiFi/SHS/app control). |
